Measurement speed/volume of blood used60 samples/hour
CBC+DIFF mode: ≤20 µl
Usage environmentWide range input: a.c. 100-240V, 50/60Hz
Temperature: 15-30℃
Humidity: 20-85﹪
Atmospheric pressure: 70-106KPa
Altitude: ≤3000m
Measurement technologySemiconductor Laser Scattering Technology
Flow cytometric techniques
Three-dimensional scatter plot analysis technology
Electrical impedance measurement technology
Cyanide-free HGB measurement technology
Storage CapacityStorage of 50,000 results (including histograms, scatter plots,patient information)
LCD touch screen10.4 inches
Resolution 800*600
ModeCBC+DIFF mode
Intravenous whole blood mode, pre-diluted peripheral blood mode, and Anticoagulated peripheral whole blood mode
Extended Interface1 network port, 4 USB
Two-way LIS system supports HL7 protocol
External USB printer or WIFI connection (optional)
Built-in RFID reader scanning (optional)
Size / WeightW592*H465*D641(mm)
About 46kg
Measurement items
Reported parameters (26 items)：
WBC、Neu#、Lym#、Mon#、Eos#、Bas#、Neu%、Lym%、Mon%、Eos%、Bas%、RBC、HGB、HCT、MCV、MCH、MCHC、RDW-CV、RDW-SD、PLT、MPV、PDW-CV、PDW-SD、PCT、
P-LCC、P-LCR
Study parameters (10 items):
*NLR、*PLR、*ALY#、*ALY%、*LIC#、*LIC%、*PLT-C#、*PLT-C%、*NRBC#、*NRBC%
Two scatter plots, one 3D scatter plot
plot (as needed)
call up 2 2D plots), one WBC/BASO
scatter plot, the 2 histograms
(RBC histogram, PLT histogram)
