Measurement speed/volume of blood used
60 samples/hour
CBC+DIFF mode: ≤20 µl
Use environment
Wide range input: a.c. 100-240V,50/60Hz
Temperature: 18-35°C
Humidity: ≤70﹪
Atmospheric pressure: 70-106KPa
Altitude: ≤2000m
Measurement technology
Semiconductor laser scattering technology
Flow cytometry
Three-dimensional scatter plot analysis technology
Electrical impedance measurement technology
Cyanide-free HGB measurement technology
Storage capacity
More than 100,000 copies stored
(including histogram, scatter plot, patient information)
LCD touch screen
10.4 inches
Resolution 800*600
Measurement mode
CBC+DIFF mode
Venous whole blood mode, pre-diluted peripheral blood mode, and
Anticoagulated peripheral whole blood mode
Expansion interface
1 network port, 4 USB
Two-way LIS system supports HL7 protocol
External USB printer or WIFI connection (optional)
Built-in RFID reader scanning (optional)
Size/Weight
WXHXD.
325mmX465mmX475mm
Approx 28kg
Measurement items
Reported parameters (26 items)：
WBC、Neu#、Lym#、Mon#、Eos#、Bas#、Neu%、Lym%、Mon%、Eos%、Bas%、RBC、HGB、HCT、MCV、MCH、MCHC、RDW-CV、RDW-SD、PLT、MPV、PDW-CV、PDW-SD、PCT、
P-LCC、P-LCR
Study parameters (10 items):
*NLR、*PLR、*ALY#、*ALY%、*LIC#、*LIC%、*PLT-C#、*PLT-C%、*NRBC#、*NRBC%
Two scatter plots, one 3D scatter plot (as needed)
call up 2 2D plots, one WBC/BASO scatter plot, the 2 histograms (RBC histogram, PLT histogram)
